Belt Driven Lathe Machine
Brand Belt type cone pulley heavy Duty Lathe Machine
₹
221,000.00
₹250,000.00
| Others: | |
| Center height | 250 mm |
| Admit Between Centers | 555 mm |
Delivery: 10-15 days from the date of PO along with advance but we keep these machines in stock and will be confirmed exact delivery schedule at the of order finalization
One Year against any manufacturing defect
Belt Type Cone Pulley Medium Duty Lathe Machine
₹
205,000.00
₹235,000.00
| General Details: | |
| Modal | 1825/6' x10x80 |
| Others: | |
| Admit Between Centers | 1041 mm |
| Bed Width | 280 mm |
| Center height | 250 mm |
| Lead Screw TPI | 32/4 TPI |
| Length of bed | 1800mm (6') |
| Metric Thread | 0.5-7 mm |
| No of spindle speed | 6 Nos |
| Quill travel | 139 mm |
| Range of speed | 46-550 rpm |
| Spindle Bore | 80 mm |
| Spindle Taper | MT4 |
| Swing Over bed | 500 mm |
| Swing Over Cross slide | 375 mm |
| Swing Over Gap | 600 mm |
| Tail Stock dia | 50 mm |
| Tail stock taper | MT4 |
| TPI Thread | 4-48 TPI |
| Weight Appx | 825 Kgs |
In stock nd Immediate
One year against any manufacturing defect
Belt Type Cone Pulley Heavy Duty Lathe Machine
₹
265,000.00
₹325,000.00
| General Details: | |
| Modal | PHDS:7'x12x80 |
| Others: | |
| Admit Between Centers | 1050 mm |
| Bed Width | 324 mm |
| Center height | 300 mm |
| Lead Screw TPI | 4 TPI |
| Length of bed | 7' |
| Metric Thread/Nos | 0.5-7 mm/13 |
| No of spindle speed | 8 Nos |
| Quill travel | 200 mm |
| Range of speed | 40-500 rpm |
| Spindle Bore | 80mm |
| Spindle Taper | MT4 |
| Swing Over bed | 600 mm |
| Swing Over Cross slide | 400mm |
| Swing Over Gap | 750 mm |
| Tail Stock dia | 50 mm |
| Tail stock taper | MT4 |
| TPI Thread | 4-48 TPI |
| Weight Appx | 1400 Kgs |
Introducing our Belt Driven Lathe Machine, a high-quality and reliable tool for precision metalworking. This machine is designed to provide exceptional accuracy and efficiency, making it ideal for a wide range of applications. With its sturdy construction and powerful motor, it can handle even the toughest materials with ease. The belt-driven system ensures smooth and consistent operation, while the adjustable speed control allows for precise adjustments to suit your specific needs. Whether you're a professional machinist or a DIY enthusiast, this lathe machine is sure to exceed your expectations. Invest in the best and experience the difference today!
In stock and immediate
One year against manufacturing defect
LIGHT Duty Lathe Machine
₹
115,000.00
₹140,000.00
| General Details: | |
| Modal | PLDL4.6" |
| Others: | |
| Motor Power ( 1440 RPM) | 1 HP |
| Admit between centers | 650 mm |
| Center height | 165 mm |
| Cross Slide Travel | 225 mm |
| Lead Screw Pitch | 4 TPI |
| Length of bed | 1370 mm (4'6") |
| Max Swing over bed | 330 mm |
| Max Swing Over Cross Slide | 180 mm |
| No of Spindle Speed/RPM | 8 Nos/30-825 RPM |
| Spindle bore | 38 mm |
| Tapper of center in Head and T.S. | MT 3 |
| Weight approx | 450 kgs |
| Width of Bed | 280 mm |
The LIGHT Duty Lathe Machine by Pentagon Machines and Tools is a precision tool designed for small to medium-sized workpieces. It features a compact design that makes it suitable for use in a wide range of settings, including machine shops, workshops, and factories. This lathe machine is equipped with a powerful motor that delivers high-speed performance, allowing for efficient and accurate machining of various materials, including metals, plastics, and wood. The machine comes with various features such as a digital readout, a quick-change tool post, and a coolant system, making it highly versatile and user-friendly.
In stock and immediate
One year against manufacturing defect
