Horizontal Lathe Machine
High Speed Precision Lathe Machine
₹
925,000.00
₹985,000.00
| General Details: | |
| Modal | C6266Fx1500 |
| Others: | |
| Packing size (L*W*H) (mm) | 3168*1130*1392 mm |
| Spindle hole | 80 mm |
| Spindle nose | DB |
| Spindle speeds (Number) | 10-1400 RPM (24 Steps) |
| Taper of tailstock sleeve | MT5 |
| Travel of tailstock sleeve | 150 mm |
| Inner Taper of spindle nose | 90(120) |
| Admit between centers | 1500 mm |
| Cross slide travel | 320 mm |
| Dia. of tailstock sleeve | 75 mm |
| Inch threads range (Kinds) | 1/2-24 (28 Kinds)tpi |
| Main motor power | 7.5 KW |
| Max. swing in gap width (mm) | 830x210 |
| Max. swing over bed (mm) | 660 |
| Max. swing over carriage (mm) | 400 |
| Metric threads range(Kinds) | 1-192 (44 Kinds)mm |
| Module threads range (Kinds) | 0.25-48 (39 Kinds)mm |
| Net Weight/Gross Weight | 1500/2492 Kgs |
Introducing our state-of-the-art Horizontal Lathe Machine, designed to revolutionize your machining operations. Crafted with precision and durability in mind, this machine boasts a robust construction and exceptional performance. Equipped with advanced features, it offers unparalleled accuracy and efficiency, ensuring flawless results every time. The user-friendly interface allows for effortless operation, while the spacious work area accommodates a wide range of workpieces. With its high-speed spindle and cutting-edge technology, this Horizontal Lathe Machine guarantees optimal productivity and versatility. Whether you're in the automotive, aerospace, or manufacturing industry, this machine is the perfect addition to your workshop, delivering unmatched precision and reliability.
In stock and immediate
One year against any manufacturing defect
High Speed all Geared High Precision Lathe Machine
₹
1,815,000.00
₹1,885,000.00
| General Details: | |
| Modal | C6266Bx2000 |
| Others: | |
| Admit between centers | 2000 mm |
| Bed width | 400 mm |
| Compound rest travel | 230 mm |
| Cross-section size of toolshank | 25*25 mm |
| Dia. of tailstock sleeve | 90 mm |
| Inch threads range (Kinds) | 7/16-80 TPI OR 40mm x 12mm |
| Main motor power | 7.5 KW (10 HP) |
| Max. swing in gap (mm) Dia. | 900 |
| Max. swing over bed (mm) Dia. | 660 |
| Max. swing over cross slide (mm) Dia. | 440 |
| Max.Cross slide travel | 368 mm |
| Module threads range (Kinds) | 0.25-60MP(46Kinds) |
| Net Weight/Gross Weight | 3345/ 3835 Kgs |
| Packing size (L*W*H) (mm) | 3740*1140*1840 mm |
| Range of Spindle Speed | 25-1600 RPM |
| Spindle hole Dia. | 105 mm |
| Spindle nose | D1-8 |
| Spindle speeds (Number) | 16 |
| Taper of Spindle Hole/Bore | Dia.113mm(120)/MT5 |
| Taper of tailstock sleeve / Quill Taper | MT5 |
| Travel of tailstock sleeve | 235 mm |
Introducing our state-of-the-art Horizontal Lathe Machine, designed to revolutionize your machining operations. Crafted with precision and durability in mind, this machine boasts a robust construction and exceptional performance. Equipped with advanced features, it offers unparalleled accuracy and efficiency, ensuring flawless results every time. The user-friendly interface allows for effortless operation, while the spacious work area accommodates a wide range of workpieces. With its high-speed spindle and cutting-edge technology, this Horizontal Lathe Machine guarantees optimal productivity and versatility. Whether you're in the automotive, aerospace, or manufacturing industry, this machine is the perfect addition to your workshop, delivering unmatched precision and reliability.
In Stock and immediate
One year against manufacturing defect
